Main characteristic:
1) Special design in blade;
2) Suit for crush all kind of the flake, the basins, automobile tire, plastic bathtub, etc.
3) Materials can be directly feeded in, needn to flatten.
Main technical parameters：
|
Model |
SWP500B-2 |
SWP650B-2 |
SWP800B-2 |
SWP1000B-2 |
|
Spinning blade |
6 |
6 |
6 |
6 |
|
Fixed blade |
4 |
4 |
4 |
4 |
|
Screen aperture(mm) |
12 |
12 |
12 |
12 |
|
Effectie caliber(mm) |
500×400 |
650×400 |
800×500 |
1000×550 |
|
Crushing capability(kg/h) |
550-650 |
750-850 |
900-1000 |
1100-1300 |
|
Motor power(kw) |
11 |
15 |
30 |
30 |
|
Outline dimension(mm) |
1100×1650×1750 |
1350×1800×1900 |
1600×1900×2100 |
1750×1900×2200 |
|
Weight(kg) |
750 |
900 |
1800 |
2000 |
|
