Main characteristics:
SWP530 D, 680 D model rubber & plastic crushers, adopts the unique design of air blower, improves the efficiency of crushing collecting type of panel, pipe, net linear nylon, membrane, etc, reduces labour intensity, it is a kind of comparatively ideal new model at present.
Main technical parameters:
|
Model |
SWP530D-3 |
SWP680D-3 |
|
Spinning blade |
4 |
4 |
|
Fixed blade |
2 |
2 |
|
Screen aperture(mm) |
12 |
12 |
|
Effectie caliber(mm) |
530×150 |
680×220 |
|
Crushing capability(kg/h) |
700-800 |
900-1000 |
|
Motor power(kw) |
15 |
18.5 |
|
Outline dimension(mm) |
1700×1100×1250 |
1800×1100×1400 |
|
Weight(kg) |
750 |
950 |
|
