Specifications:
This machine is suitable to cut non-woven, film, paper material. It’s the best auxiliary equipment for manual non-woven bag.
Detailed Product Description:
1.The machine adopts stepper motor control fixed length truncated. A photoelectric tracking correction system;
2. Adopts automatic photoelectric rectification device in Feeding System;
3.This machine is equipped with ruffled, hot-close ultrasonic, slicing function, set light, electricity as a whole,simple operation, accurate slicing, high mechanical stability, low noise advantages, it is the ideal equipment for the non-woven fabric processing;
4. Many functions like:Motor frequency control of motor speed, automatic counting, alarm parking, tension control;
5.Products cutting adopted the heavy and good quality tool cutting, neat and no edge 6. Feed motor : 0.8kw;
7. Computer controlling, fixed length settings;
8. Automatic counting, sound and light alarming;
9. Photoelectric tracking control, accurate truncated length .if no product, then machine stop automatically;
10. Machine match: all kinds of wearing parts, a set of tools.
Main Technical Parameter:
|
Type |
HQJ-1200 |
|
Cutting Speed （pcs/min） |
20-100 |
|
Bag width （mm） |
100-1150 |
|
Bag length （mm） |
100-1500 |
|
Material Thickness (GSM) |
30-150 |
|
Inserting Size (mm) |
30-90 |
|
Power （V） |
220 |
|
The total power (KW) |
5 |
|
The weight of the machine (kg) |
800 |
|
The weight of the machine and packaging (kg) |
1100 |
|
Overall Dimension (LxWxH) (mm) |
5200х1100х1600 |
|
