Features：
1.Special design for thin wall products, such as disposable food
container, cover of electrical product, spare parts of communication device,
which are required fast speed injection;
2. Short cycle time to enhance production output and save labor cost.
3. Different types of drive to drive to satisfy different
requirements of customers.
4. Easy to operate, good quality HMI and digit control, convenient to set
parameters.
Parameter:
|
Type
|
HD900-300
|
HD1300-300
|
HD1600-473
|
HD2000-601
|
|
CLAMPING UNIT
|
|
|
|
|
|
Clamping
force, KN
|
900
|
1300
|
1600
|
2000
|
|
Opening
Stroke, mm
|
320
|
400
|
440
|
490
|
|
Max. daylight,
mm
|
680
|
820
|
940
|
1040
|
|
Platen Size,
mm*mm
|
540*540
|
620*620
|
705*705
|
775*755
|
|
Space between
bars, mm*mm
|
360*360
|
410*410
|
460*460
|
510*510
|
|
Max. mold
height, mm
|
360
|
420
|
500
|
550
|
|
Min. mold
height, mm
|
130
|
150
|
160
|
230
|
|
Ejector
stroke, mm
|
100
|
125
|
140
|
140
|
|
Ejector force,
KN
|
35
|
42
|
49
|
65
|
|
INJECTION UNIT
|
|
|
|
|
|
Screw
diameter, mm
|
30
36 42
|
30
36 42
|
36
42 46
|
42
46 52
|
|
Screw L/D ratio,
|
20
20 17
|
20
20 17
|
23
20 18
|
22
20.5 18
|
|
Injection
Pressure, Mpa
|
266
185 136
|
266
185 136
|
259
190 159
|
213
177 139
|
|
Shot volume,
cm3
|
113
163 222
|
113
163 222
|
183
249 299
|
284
340 435
|
|
Shot weight
(ps), g/OZ
|
106/3.8
153/5.4 208/ 7.4
|
106/3.8
153/5.4 208/7.4
|
172/6.1
234/8.3 281/9.9
|
267/9.4
320/11.3 409/14.5
|
|
Injection
rate, g/sec
|
68
97 133
|
84
121 170
|
108
147 176
|
189
227 290
|
|
Max linear
injection speed, mm/s
|
100
|
120
|
110
|
145
|
|
Screw stroke,
mm
|
160
|
160
|
180
|
205
|
|
Screw speed,
rpm
|
220
|
270
|
290
|
360
|
|
POWER UNIT
|
|
|
|
|
|
Hydraulic
system pressure, Mpa
|
17.5
|
17.5
|
17.5
|
17.5
|
|
Pump motor
power, kw
|
11
|
15
|
18.5
|
22
|
|
Heater power,
kw
|
6
|
6
|
7.5
|
9.8
|
|
GENERAL
|
|
|
|
|
|
Dry circle
time, sec
|
|
|
|
|
|
Oil tank
capacity, L
|
180
|
210
|
260
|
340
|
|
Machine
weight, kg
|
2.8
|
3.8
|
4.5
|
5.8
|
|
Dimension
(LxWxH)
|
3.8*1.1*1.7
|
4.2*1.2*1.8
|
4.8*1.3*1.8
|
5.8*1.4*2.1
|
|
Type
|
HD2880-915
|
HD3300-1341
|
HD4000-1902
|
HD5000-2495
|
|
CLAMPING UNIT
|
|
|
|
|
|
Clamping
force, KN
|
2880
|
3300
|
4000
|
5000
|
|
Opening
Stroke, mm
|
550
|
600
|
710
|
830
|
|
Max. daylight,
mm
|
1160
|
1300
|
1440
|
1680
|
|
Platen Size,
mm*mm
|
850*850
|
985*985
|
1050*1050
|
1260*1260
|
|
Space between
bars, mm*mm
|
610*610
|
670*670
|
740*720
|
820*780
|
|
Max. mold
height, mm
|
610
|
700
|
730
|
850
|
|
Min. mold
height, mm
|
280
|
300
|
300
|
300
|
|
Ejector
stroke, mm
|
145
|
180
|
210
|
220
|
|
Ejector force,
KN
|
77
|
77
|
110
|
135
|
|
INJECTION UNIT
|
|
|
|
|
|
Screw
diameter, mm
|
46
52 60
|
52
60 68
|
60
68 75
|
68
75 83
|
|
Screw L/D
ratio,
|
23
19.5 17.5
|
21
21 19
|
21
21 19
|
21
21 19
|
|
Injection
Pressure, Mpa
|
230
180 135
|
226
169 132
|
217
169 139
|
208
171 140
|
|
Shot volume,
cm3
|
407
520 693
|
595
792 1017
|
877
1126 1370
|
1198
1458 1786
|
|
Shot weight
(ps), g/OZ
|
382/13.5
489/17.2 651/23
|
559/
19.7 744/26.2 956/33.7
|
824/29.1
1058/37.3 1287/45.4
|
1126/39.7
1370/48.3 1678/59.2
|
|
Injection
rate, g/sec
|
228
292 388
|
261
347 446
|
336
432 526
|
429
522 639
|
|
Max linear
injection speed, mm/s
|
130
|
125
|
125
|
125
|
|
Screw stroke,
mm
|
245
|
280
|
310
|
330
|
|
Screw speed,
rpm
|
295
|
240
|
241
|
179
|
|
POWER UNIT
|
|
|
|
|
|
Hydraulic
system pressure, Mpa
|
17.5
|
17.5
|
17.5
|
17.5
|
|
Pump motor
power, kw
|
30
|
37
|
45
|
55
|
|
Heater power,
kw
|
11.5
|
13.8
|
18
|
22
|
|
GENERAL
|
|
|
|
|
|
Dry circle
time, sec
|
|
|
|
|
|
Oil tank
capacity, L
|
420
|
460
|
630
|
810
|
|
Machine
weight, kg
|
8
|
10.8
|
15
|
19.5
|
|
Dimension
(LxWxH)
|
6.2*1.5*2.2
|
6.8*1.62*2.3
|
7.2*1.65*2.3
|
8.7*2.1*2.3
|
|
