Applicability:
Pharmaceutical, food, stationery, cosmetic, electronic products, toys, etc.
Product specify:
1） Adopts PLC program controlling and man-machine interface.
2) Totally enclosed packing type.
3) Feeding, wrapping, bag-making, sealing-cutting, collecting waste, neatening, shrinking and packaging are finished in one process automatically.
4) Constant temperature superfine aluminum alloyed sealing blade, anti-stickiness, slight sealing, non-coking, non-smoking, unpolluted.
5) The blade rebounds while cutting objects.
6) Adjust packing size without changing mold when changing packing objects.
7) Conveyor belts covers with adiabatic tubes, so as not to scald and damage film.
8) The dual hot-air cycling temperature in the shrinking chamber can be adjusted optionally.
9) Conveyor motor adopts electronic stepless speed regulation technology, and has long lifetime and low noise.
Main Technical Parameters:
|
Model |
BMD-450B |
|
Electric Power |
380V 50Hz |
|
Power(kw) |
7 |
|
Max Conveying speed(m/min) |
10 |
|
Max Packing Size(mm) |
400×320 |
|
Overall Dimensions(mm) |
1600×600×1260 |
|
Weight(kg) |
200 |
|
Main Material |
Stainless steel |
|
Model |
BS-400LB |
|
Electric Power |
220V 50Hz |
|
Power（kw） |
1.25 |
|
Max Sealing Size(mm) |
560×400×125 |
|
Max Packing speed(pieces/min) |
35 |
|
Air pressure(Mpa) |
0.5 |
|
Overall Dimensions(mm) |
1500×770×1450 |
|
Weight(kg) |
350 |
|
Main Material |
Stainless steel |
|
