Use:
Suitable for crushing engineering plastic and plastic blocks .
Features :
Adopts revolving claw-shaped blade and combined blades .The stress is equally pressed , this makes the machine stable and makes little noises . It is very easy to change the mesh , efficiency and energy saving .flake cutter blade is between claw and flate cutter blade.it is suitable for recycle and restore of conventional sheets,tube plastic,profiles,packing plastic extrusion mould products and runners.general operations adopted whith airtight sealed bearing to alow long hours rotation.well designed cutter blade is to ensure the balance of pellets sizes after crus.cutter base is special heat treated,and the appearance is elegant.
Main technical parameters：
|
Model |
WSG230 |
WSG300 |
WSG400 |
WSG500 |
WSG600 |
WSG800 |
|
Crushing caliber(mm) |
230×200 |
310×200 |
410×235 |
515×290 |
610×320 |
815×470 |
|
Output(kg/h) |
100-150 |
150-200 |
200-250 |
300-350 |
350-450 |
450-600 |
|
Fixed cutter |
2 |
2 |
2 |
2 |
4 |
4 |
|
Rotary cutter |
6 |
9 |
12 |
15 |
18 |
24 |
|
Power(kw) |
4 |
5.5 |
7.5 |
11 |
15 |
22/30 |
|
Overall dimension(L×W×H cm) |
96×62×119 |
100×72×129 |
103×84×139 |
123×101×163 |
132×111×183 |
173×149×230 |
|
Weight(kg) |
288 |
432 |
500 |
900 |
1100 |
2000 | |
