Use:
The thermoforming line can produce various kind of disposable plastic containers of cooling drinks,yogurt,ice-cream,fast food,or instant noodle,as well as different kinds of merchandise packages of medicine,toy,tourist. textile and light industry,etc.
Technical Specifications:
|
Model |
ZY660-A/B |
|
Sheet Materials |
(Hard Sheet) PP.PS.PET.ABS(decompose Sheet) EPS |
|
Sheet Width(mm) |
400-650 |
|
Sheet Thickness(mm) |
0.25-2.5 |
|
Max.Forming Area(mm) |
620×300 |
|
Max.Forming depth(mm) |
166 |
|
Forming Pressure(Mpa) |
0.5-0.8 |
|
Productivity(mould/min) |
5-38 |
|
Rated Heading Power(kw) |
67 |
|
Starting Power(kw) |
7.5 |
|
Total Weight(t) |
4.5 |
|
Water Temperature QUOTE |
>30 |
|
Overall Dimensions(mm) |
3000×1800×2500 |
|
Sheet Travel Length Adjustable(mm) |
100-400 |
|
